After the AC input voltage is filtered by the rectifier circuit, the high-voltage DC power is obtained. The 1500A 6V DC electrolytic rectifier for silver electrolysis uses "variable frequency conversion" to invert the high-voltage direct current into about 30kHz high-frequency alternating current, which is then converted into the secondary voltage by a high-frequency transformer, and then filtered by the high-frequency rectifier circuit to obtain the required output voltage. Sampling of output voltage and current is made by the control circuit, and then the signal of pulse width modulation (PWM) for controlling the inverter circuit is generated after closed-loop feedback to keep the output voltage and current steady.
Product Applications
The TBSB-1500A/6V is ideal for high-purity silver refining (up to 99.99%), silver electrowinning from solutions, silver recovery from scrap or photographic waste, laboratory-scale silver electrolysis research, and small to medium-scale precious metal refineries.
Field application diagram
Technology Advantages
› High Reliability
› Easy to use and repair
› Fault Self-diagnosis
› High accuracy of steady flow
› Soft startup, soft shutdown
› On/Off loop disturbance-free switch
› High efficiency (≥91%)
› Low ripple (≤3%)
› Compact & lightweight
› Water-cooled
› RS485 remote control
Cooling Type for Electrolytic Rectifier
Air Cooling:Heat dissipation fan + air duct + comb heat sink
Water Cooling：Built-in water circulation line
Technical Parameters
Type of characteristics
Parameters
Technical Requirements
Input characteristics
Rated input voltage
Three-phase AC415V ± 10% 50Hz, Compliance with National Power Quality Standards
Rated input current
AC 14.9 A
Rated input power
10.4 KVA
Rated input power factor
COSΦ≥0.95
Output characteristics
Output voltage
DC 0～6V (Adjustable from 1% to 100%)
Output current
DC 0～1500A(Adjustable from 1% to 100%)
Precision of steady current
≤1%
Precision of stable voltage
≤1%
Displayed precision
1A，0.01V
Current ripple coefficient
≤3%（I≥50%Id）
Rated output power
≥91%
Insulation characteristic
Insulation resistance
Input - Output: ≥5MΩ
Input - Cabinet: ≥5MΩ
Output - Cabinet: ≥5MΩ
Protective characteristics
With self-protection function under non-normal cases such as over-voltage, over-current, overload, short circuit and overheating
Other characteristics
Noise
≤60dB
Running state
Continuous full load run of product
Load level
Level II
Insulation grade of the transformer
Grade B
*OK to Customized according to requirements*
Solution
Liyuan will keep up with the world’s latest technology closely, and uphold the concept of providing customers with high-quality power supplies and professional integrated services.
With advanced design and rich experience in rectifier manufacturing, we will provide the best power solutions as well as the most stable and efficient power supply for users both at home and abroad.
Technical Capability
LIYUAN rectifier is the most competitive brand in China
Company relies on strong technology research and development cooperation basis, created a number of advanced technology, in recent 3 years amounted to more than 30 to apply for a patent, which has nearly 10 patents of invention.
Equipped with the national electric power transformation and control engineering technology research center (branch), and has set up a loan enterprise academician workstation.
Strict implementation of ISO quality management system, and through the CE safety certification, has been implementing ERP management for many years, to achieve the network, systematic computer control, the formation of a standard, efficient modern management system.
Qualification certification
Liyuan adhere to innovation and the continuous improvement of power conversion efficiency and product quality.
The increasing R&D investment every year, and cooperation with China’s well-known universities, we has established the research center of national electric power conversion and control engineering technology.
Especially the related core patents of high-power synchronous rectifier power supply, stay ahead of the whole industry in China.
The ISO 9001 quality management system has been fully implemented in Liyuan, including quality inspection of components in warehouse, production process inspection, and final product inspection.
We adopt advanced scientific quality management system and the most stringent testing methods in the whole process to ensure the stability and reliability of products.
Service
› Packing
1.Small size rectifier packing in carton box separately.
2.Large size rectifier will be packed in wooden case.
3.We guarantee that all the packing is intact when it reaches its destination.
› Shipping
1.30-45 Days after payment.
2.Transport: DHL, FEDEX, UPS, Air shipping, Boat shipping
3.You may choose our shipping partner or your own partner.
› Maintenance
We are pleasant to share our theory and experience on equipment maintenance with users.
We are pleasant to interact with users to collect their tips and know-hows on equipment maintenance.
The module “Maintenance” here is intended to help users solve various problems they possibly encounter during equipment maintenance…
If you need other electrolytic rectifiers, we can custom design them according to customer requirements. Please contact us.
